Rysunek pomocniczy:

Z funkcji trygonometrycznych otrzymujemy:

$\frac{H}{r}=\mathrm{tg}\alpha$

$H=r\mathrm{tg}\alpha$

oraz

$\frac{H}{h}=\cos \beta$

$\frac{H}{\cos \beta }=h$

$\frac{r\mathrm{tg}\alpha }{\cos \beta }=h$

oraz

$\frac{r}{l}=\cos \alpha$

$\frac{r}{\cos \alpha }=l$



Z tw. Pitagorasa otrzymujemy:

$h^2+x^2=l^2$

${\left(\frac{r\mathrm{tg}\alpha }{\cos \beta }\right)}^2+x^2={\left(\frac{r}{\cos \alpha }\right)}^2$

$\frac{r^2{\mathrm{tg}}^2\alpha }{{\cos }^2\beta }+x^2=\frac{r^2}{{\cos }^2\alpha }$

$x^2=\frac{r^2}{{\cos }^2\alpha }-r^2\frac{{\sin }^2\alpha }{{\cos }^2\alpha {\cos }^2\beta }$

$x^2=r^2\left(\frac{1}{{\cos }^2\alpha }-\frac{{\sin }^2\alpha }{{\cos }^2\alpha {\cos }^2\beta }\right)$

$x^2=r^2\left(\frac{{\cos }^2\beta }{{\cos }^2\alpha {\cos }^2\beta }-\frac{{\sin }^2\alpha }{{\cos }^2\alpha {\cos }^2\beta }\right)$

$x=r\sqrt{\frac{{\cos }^2\beta -{\sin }^2\alpha }{{\cos }^2\alpha {\cos }^2\beta }}$



Zatem otrzymujemy:

$P=\frac{1}{2}\cdot 2x\cdot h$

$P=x\cdot h$

$P=r\sqrt{\frac{{\cos }^2\beta -{\sin }^2\alpha }{{\cos }^2\alpha {\cos }^2\beta }}\cdot \frac{r\mathrm{tg}\alpha }{\cos \beta }$

$P=\frac{r^2\mathrm{tg}\alpha }{\cos \beta }\cdot \sqrt{\frac{{\cos }^2\beta -{\sin }^2\alpha }{{\cos }^2\alpha {\cos }^2\beta }}$



Zauważmy, że:

$\frac{{\cos }^2\beta -{\sin }^2\alpha }{{\cos }^2\alpha {\cos }^2\beta }=\frac{{\cos }^2\beta -{\sin }^2\alpha \left({\cos }^2\beta +{\sin }^2\beta \right)}{{\cos }^2\alpha {\cos }^2\beta }=$

$=\frac{{\cos }^2\beta -{\sin }^2\alpha {\cos }^2\beta -{\sin }^2\alpha {\sin }^2\beta }{{\cos }^2\alpha {\cos }^2\beta }=$

$=\frac{\left(1-{\sin }^2\alpha \right){\cos }^2\beta -{\sin }^2\alpha {\sin }^2\beta }{{\cos }^2\alpha {\cos }^2\beta }=$

$=\frac{{\cos }^2\alpha {\cos }^2\beta -{\sin }^2\alpha {\sin }^2\beta }{{\cos }^2\alpha {\cos }^2\beta }=$

$=1-\frac{{\sin }^2\alpha {\sin }^2\beta }{cs{o}^2\alpha {\cos }^2\beta }=1-{\mathrm{tg}}^2\alpha {\mathrm{tg}}^2\beta$



Zatem możemy zapisać:

$P=\frac{r^2\mathrm{tg}\alpha }{\cos \beta }\cdot \sqrt{1-{\mathrm{tg}}^2\alpha {\mathrm{tg}}^2\beta }$
